Measurement of Surface

• Measurement of Surface can be measured using various techniques, each based on different physical principles.
• Below are the commonly used methods:

1. Capillary Rise Method for Measurement of Surface and Interfacial Tensions

• Principle:

  • This method relies on the height a liquid rises in a capillary tube due to surface tension.
  • The liquid rises because of adhesive forces between the liquid and the capillary walls, balanced by gravitational force.

• Formula:

  • • • • $\gamma = \frac{h r \rho g}{2 \cos \theta}$


  • where:
    • γ = surface tension (N/m)
    • h = height of liquid rise (m)
    • r = radius of capillary tube (m)
    • ρ = liquid density (kg/m³)
    • g = gravitational acceleration (m/s²)
    • θ = contact angle

• Advantages:

  • Simple and inexpensive
  • Suitable for clean liquids

• Limitations:

  • Contact angle (θ) can be difficult to measure
  • Not suitable for highly viscous or contaminated liquids

2. Drop Count Method for Measurement of Surface and Interfacial Tensions

• Principle:

  • Measures surface tension by counting the number of drops formed from a specific volume of liquid.
  • A liquid with higher surface tension forms fewer but larger drops.

• Formula:

  • • • • $\gamma \propto \frac{V}{N}$

  • where:
    • γ = surface tension
    • V = volume of liquid (mL)
    • N = number of drops

• Advantages:

  • Simple and requires minimal equipment

• Limitations:

  • Drop formation is influenced by external factors like temperature and humidity
  • Less accurate than other methods

3. Drop Weight Method (Stalagmometric Method)

• Principle:

  • Based on the weight of a drop detaching from a capillary tube.
  • The surface tension balances the gravitational force until the drop detaches.

• Formula (for a perfect sphere assumption):

  • • • $\gamma = \frac{mg}{2\pi r}$

• where:
  • m = mass of the drop (kg)
  • g = gravitational acceleration (m/s²)
  • r = radius of the capillary (m)

• Advantages:

  • More precise than the drop count method
  • Useful for studying interfacial tension

• Limitations:

  • Correction factors are needed due to non-spherical drop shapes
  • Requires accurate mass measurement

4. Wilhelmy Plate Method

• Principle:

  • A thin plate (often platinum) is suspended and partially submerged in a liquid.
  • The force exerted by the liquid’s surface tension on the plate is measured.

• Formula:

  • • • • $\gamma = \frac{F}{l}$

  • where:
    • γ = surface tension (N/m)
    • F = force due to surface tension (N)
    • l = perimeter of the plate in contact with the liquid (m)

• Advantages:

  • Highly accurate and suitable for dynamic measurements
  • Can measure both surface and interfacial tensions

• Limitations:

  • Requires precision in force measurement
  • Sensitive to contaminants

5. Ring Detachment Method (Du Noüy Ring Method)

• Principle:

  • A platinum ring is placed on a liquid surface and slowly pulled upward.
  • The maximum force required to detach the ring from the surface is measured.

• Formula:

  • • • • $\gamma = \frac{F_{\text{max}}}{4\pi R}$

    • γ = surface tension (N/m)
    • Fmax​ = maximum detachment force (N)
    • R = radius of the ring (m)

• Advantages:

  • Suitable for both surface and interfacial tension
  • Provides consistent results

• Limitations:

  • Requires calibration and correction factors
  • Not suitable for highly viscous liquids
