Potentiometry

• Potentiometry is an electroanalytical technique that measures the potential difference (voltage) between two electrodes in an electrochemical cell with no or negligible current flow.
• The potential difference is related to the concentration of ions or molecules in a solution and can be determined using the Nernst equation or other relevant relationships.
• Potentiometry is widely used in fields such as pharmaceutical analysis, environmental monitoring, and quality control of food and beverages.

Components of a Potentiometric Measurement

• In a typical potentiometric measurement, an electrochemical cell consists of two electrodes:

• Working Electrode (Indicator/Sensing Electrode)

  • This electrode is sensitive to the analyte of interest, responding to its concentration in the solution.

• Reference Electrode

  • The reference electrode maintains a stable and well-defined potential, serving as a reference point for measuring the potential difference between the two electrodes.

Types of Potentiometric Electrodes

1. Ion-Selective Electrodes (ISEs)

   • ISEs are sensitive to specific ions in a solution and develop a potential in response to their concentration, as described by the Nernst equation.
   • The most common ISE is the glass electrode, used for pH measurements as it is selective for hydrogen ions (H+).
   • Other ISEs include solid-state electrodes, liquid membrane electrodes, and gas-sensing electrodes, which are selective for various cations (e.g., Na+, K+, Ca2+) and anions (e.g., Cl-, NO3-).

2. Redox Electrodes

   • Redox electrodes measure the potential of redox-active species in a solution, with the potential being related to their concentration and redox state.
   • These electrodes are typically made from inert metals, such as platinum or gold, and are often combined with a reference electrode to form a single, combined electrode.

3. Potentiometric Biosensors

   • These sensors incorporate a biological recognition element (e.g., enzyme, antibody, receptor) that selectively binds to the analyte of interest, triggering a measurable change in potential.
   • Potentiometric biosensors have applications in pharmaceutical and biomedical fields, including drug monitoring, diagnostic tests, and environmental analysis.

Application of Potentiometry

1. pH Measurement

   • Used to measure pH using a glass electrode as the indicator and a reference electrode (e.g., silver/silver chloride or calomel).
   • The potential difference between the electrodes indicates the pH of the solution.

2. Ion-Selective Electrode (ISE) Measurements

   • ISEs selectively respond to specific ions such as fluoride, chloride, potassium, sodium, and calcium, and are used in water quality testing, blood analysis, and environmental monitoring.

3. Titration

   • Potentiometry monitors titrations by measuring the potential difference between the indicator and reference electrodes, allowing for accurate determination of the titration end point.

4. Quality Control

   • Common in pharmaceuticals, food, and beverages.
   • For example, chloride ion concentration in saline can be measured using ISEs, and acidity in fruit juices can be determined using pH electrodes.

5. Electroplating

   • Potentiometry controls metal deposition in electroplating by measuring the potential difference between the metal electrode and the ion-containing solution, ensuring consistent plating quality.
